Mechanical
| IP Rating | IP20 |
|---|---|
| Fitting Colour | |
| EV-TOUCAN-1MOD-EXIT-B-DA EV-TOUCAN-1MOD-S-B EV-TOUCAN-1MOD-S-B-LK EV-TOUCAN-1MOD-S-R-B-LK | Black |
| EV-TOUCAN-1MOD-S EV-TOUCAN-1MOD-S-LK EV-TOUCAN-1MOD-S-R-LK | White |
| Product Finish | Powder coated |
| Body Material | |
| EV-TOUCAN-1MOD-S EV-TOUCAN-1MOD-S-B EV-TOUCAN-1MOD-S-B-LK EV-TOUCAN-1MOD-S-LK EV-TOUCAN-1MOD-S-R-B-LK EV-TOUCAN-1MOD-S-R-LK | Zinc Annealed Steel |
| EV-TOUCAN-1MOD-EXIT-B-DA | Zinc Annealed Steel, Polycarbonate (EM gear) |
| Diffuser Material | PMMA |
Electrical
| Working Temp Range | |
|---|---|
| EV-TOUCAN-1MOD-S-B-LK EV-TOUCAN-1MOD-S-LK EV-TOUCAN-1MOD-S-R-B-LK EV-TOUCAN-1MOD-S-R-LK | -20 to 40 °C |
| EV-TOUCAN-1MOD-EXIT-B-DA | 0 to 40 °C |
| Input Frequency | 50 Hz |
| Maximum Wattage | 1.7 W |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
Driver
| Driver Type | DALI DT1 Emergency |
|---|---|
| Driver Included | Yes |
Emergency (EM suffix)
| Emergency Mode | Maintained |
|---|---|
| Emergency Output Power | 350 mW |
| Replacement Battery Code | 13972 |
| Emergency Duration | 90 mins |
| Viewing Distance | 24 m |
| Decal Size | 300 x 150 mm |
| Emergency Control | DALI Monitored (DT1) |
| DALI Monitored ~ Supports Emergency test and monitoring over DALI (IEC62386) with full compliance to IEC62386-202. | |
Warranty
| Commercial Use Warranty | 5 RTB (Total 5 Years) |
|---|
