Mechanical
| Body Material | Polycarbonate |
|---|---|
| Diffuser Material | PMMA |
| Fitting Colour | |
| EV-RAZOR-16M-PRO-B EV-RAZOR-16M-PRO-B-LK EV-RAZOR-24M-PRO-B EV-RAZOR-24M-PRO-B-LK | Black |
| EV-RAZOR-16M-PRO EV-RAZOR-16M-PRO-LK EV-RAZOR-24M-PRO EV-RAZOR-24M-PRO-LK | White |
| Installation Type | Recessed |
| IP Rating | IP20 |
Electrical
| Electrical Rating | Class II |
|---|---|
| Input Frequency | 50 Hz |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
| Maximum Wattage | 3.7 W |
| Standby Power | 1.7 W |
| Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge. | |
| Working Temp Range | 0 to 40 °C |
Driver
| Dimmable | No |
|---|---|
| Driver Included | Yes |
| Integrated Driver | Yes |
| Driver Type | |
| EV-RAZOR-16M-PRO EV-RAZOR-16M-PRO-B EV-RAZOR-24M-PRO EV-RAZOR-24M-PRO-B | DALI DT1 Emergency |
| EV-RAZOR-16M-PRO-B-LK EV-RAZOR-16M-PRO-LK EV-RAZOR-24M-PRO-B-LK EV-RAZOR-24M-PRO-LK | Wireless (IEC62386-104) with DT1 |
| Flex & Plug or Lead Length | 1200 mm |
| Wiring Type | Re-wireable Flex & Plug (2 pin) |
Emergency (EM suffix)
| Replacement Battery Code | 01302 |
|---|---|
| Emergency Classification | |
| EV-RAZOR-24M-PRO-B | "C0:E12.5, C90:E6.3" |
| EV-RAZOR-24M-PRO EV-RAZOR-24M-PRO-LK | C0:C25, C90:C20 |
| EV-RAZOR-16M-PRO EV-RAZOR-16M-PRO-LK | C0:C40, C90:C32 |
| EV-RAZOR-16M-PRO-B EV-RAZOR-16M-PRO-B-LK EV-RAZOR-24M-PRO-B-LK | C0:E12.5, C90:E6.3 |
| Emergency Control | |
| EV-RAZOR-16M-PRO EV-RAZOR-16M-PRO-B EV-RAZOR-24M-PRO EV-RAZOR-24M-PRO-B | DALI Monitored (DT1) |
| EV-RAZOR-16M-PRO-B-LK EV-RAZOR-16M-PRO-LK EV-RAZOR-24M-PRO-B-LK EV-RAZOR-24M-PRO-LK | IEC62386-104 (Wireless DT1) |
| DALI Monitored ~ Supports Emergency test and monitoring over DALI (IEC62386) with full compliance to IEC62386-202. IEC62386-104 ~ Supports wireless test and monitoring over IEC62386-104 using IEC62386-202. | |
| Decal Size | |
| EV-RAZOR-16M-PRO EV-RAZOR-16M-PRO-B EV-RAZOR-16M-PRO-B-LK EV-RAZOR-16M-PRO-LK | 200 x 100 mm |
| EV-RAZOR-24M-PRO EV-RAZOR-24M-PRO-B EV-RAZOR-24M-PRO-B-LK EV-RAZOR-24M-PRO-LK | 300 x 150 mm |
| Emergency Duration | 90 mins |
| Emergency Light Source Life | |
| EV-RAZOR-16M-PRO EV-RAZOR-16M-PRO-LK | 18Y/00M |
| EV-RAZOR-24M-PRO EV-RAZOR-24M-PRO-LK | 25Y/08M |
| EV-RAZOR-16M-PRO-B EV-RAZOR-16M-PRO-B-LK | 26Y/10M |
| EV-RAZOR-24M-PRO-B EV-RAZOR-24M-PRO-B-LK | 40Y/06M |
| AS2293.3-2018 Projection of Light source life for LED Exit signs (appendix E) Defines the projected time until the surface luminance falls below the minimum required surface luminance for an exit sign. | |
| Emergency Mode | Maintained |
| Viewing Distance | |
| EV-RAZOR-16M-PRO EV-RAZOR-16M-PRO-B EV-RAZOR-16M-PRO-B-LK EV-RAZOR-16M-PRO-LK | 16 m |
| EV-RAZOR-24M-PRO EV-RAZOR-24M-PRO-B EV-RAZOR-24M-PRO-B-LK EV-RAZOR-24M-PRO-LK | 24 m |
| Emergency Lumen Output | |
| EV-RAZOR-24M-PRO-B | 33 lm |
| EV-RAZOR-24M-PRO | 120 lm |
| Emergency Output Power | |
| EV-RAZOR-24M-PRO-B | 1350 mW |
| EV-RAZOR-24M-PRO | 1500 mW |
Compliance
| Product Design Life | 12 years |
|---|---|
| The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use. | |
| Daily Use | 24 hrs |
| The Daily Use is the recommended time required to meet the product's design life. Installations can exceed this time, however the product design life will be reduced proportionally. | |
| Standards |
|
Warranty
| Commercial Use Warranty | 8 RTB (Total 8 Years) |
|---|
