In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Lamp
Colour Rendering Index (CRI)
>80
CCT Configuration
TRI-CCT
LED Lifetime
TM-21 Test Hours
6000 hrs
Colour temperature
3000 K
1870 lm
4000 K
2100 lm
5000 K
1925 lm
Driver
Driver Type
Fixed output
Driver Included
Yes
Integrated Driver
No
Dimmable
No
Wiring Type
Re-wireable terminal block (4 pin)
Emergency (EM suffix)
Emergency Mode
Maintained
Emergency Classification
C0:D25, C90:D25
Emergency Output Power
2700 mW
Replacement Battery Code
01302
Emergency Duration
90 mins
Emergency Lumen Output
230 lm
Compliance
Product Design Life
6 years
The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use.
Standards
AS/NZS 60598.1
AS 60598.2.22
AS/NZS 61347.1
AS/NZS 61347.2.13
AS CISPR 15
AS/NZS 2293.3
Warranty
VIP Warranty
2 Onsite, 3 RTB (Total 5 Years)
VIP warranty is available to registered users and is subjected to additional terms and conditions. Register as a VIP today. Our standard warranty is return-to-base. Onsite warranty is only available to users who are registered, for sites located in the defined areas/regions and for purchases that have been registered.
Commercial Use Warranty
5Y return to base on General lighting components
6Y return to base on Emergency lighting components
