Mechanical
| Body Material | Polycarbonate |
|---|---|
| Diffuser Material | Polycarbonate |
| Fitting Colour | White |
| Installation Type | Surface mount |
| IP Rating | IP54 |
| IK Rating | IK08 |
Electrical
| Electrical Rating | Class II |
|---|---|
| Input Frequency | 50 Hz |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
| Maximum Wattage | |
| EV-PEARL-IP54 | 13.5 W |
| EV-PEARL-IP54-S | 14.5 W |
| EV-PEARL-EM-IP54-LITE | 16 W |
| EV-PEARL-EM-IP54-LITE-S | 17 W |
| Switch Type | Inline |
| Working Temp Range | 0 to 40 °C |
| Standby Power | 14.5 W |
| Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge. | |
Lamp
| CCT Configuration | TRI-CCT |
|---|---|
| Colour Rendering Index (CRI) | >80 |
LED Lifetime
| LED Lifetime | |
|---|---|
| EV-PEARL-EM-IP54-LITE EV-PEARL-EM-IP54-LITE-S EV-PEARL-IP54 | >54,000 hrs |
| EV-PEARL-IP54-S | 54000 hrs |
| This is the Reported LED Lifetime in Hours based on TM-21. Ektor does not list the projected or calculated LED lifetime, which is normally longer as TM-21 Addendum B explicitly states "The Calculated and Projected Lp(Dk) are not to be reported". This Lifetime refers to the life of a single LED however the system life is longer since the probability and binomial distribution of all LEDs in the system means that the average led is performing above the specification and compensates for the LEDs falling below. | |
| LED Lifetime Rating | L70 B10 |
| TM-21 Test Hours | 9000 hrs |
Colour temperature
| EV-PEARL-EM-IP54-LITE EV-PEARL-IP54
| |||||||||||
EV-PEARL-EM-IP54-LITE-S
| |||||||||||
EV-PEARL-IP54-S
| |||||||||||
Driver
| Dimmable | No |
|---|---|
| Driver Included | Yes |
| Integrated Driver | No |
| Driver Type | Fixed output |
| Wiring Type | |
| EV-PEARL-IP54 EV-PEARL-IP54-S | Re-wireable terminal block (3 pin) |
| EV-PEARL-EM-IP54-LITE EV-PEARL-EM-IP54-LITE-S | Re-wireable terminal block (4 pin) |
Sensor (S suffix)
| Adjustable Detection Area / Sensitivity | Yes |
|---|---|
| Adjustable Hold Time | Yes |
| Adjustable Standby Level | No |
| Adjustable Standby Period | No |
| Corridor Function | No |
| Dawn Reset | No |
| Detection Range | 6 m |
| Dusk Mode | Yes |
| Load Types | LED |
| Lux Adjustment | Yes |
| Lux Range | 3-1000 lx |
| Manual Override | No |
| Sensor Type | Microwave |
| Switched Output | Yes |
| Switched Output Rating | 125 W |
| Time Delay | 12 |
Emergency (EM suffix)
| Replacement Battery Code | 01302 |
|---|---|
| Emergency Classification | C0:D32, C90:D32 |
| Emergency Duration | 90 mins |
| Emergency Lumen Output | 312 lm |
| Emergency Mode | Maintained |
| Emergency Output Power | 3300 mW |
Compliance
| Product Design Life | |
|---|---|
| EV-PEARL-IP54-S | 6 years |
| EV-PEARL-EM-IP54-LITE EV-PEARL-EM-IP54-LITE-S EV-PEARL-IP54 | 8 years |
| The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use. | |
| Standards |
|
Warranty
| Commercial Use Warranty | |
|---|---|
| EV-PEARL-IP54 EV-PEARL-IP54-S | 5 RTB (Total 5 Years) |
| EV-PEARL-EM-IP54-LITE EV-PEARL-EM-IP54-LITE-S | 5 RTB General, 6 RTB Emergency |
| VIP Warranty | 2 Onsite, 3 RTB (Total 5 Years) |
| VIP warranty is available to registered users and is subjected to additional terms and conditions. Register as a VIP today. Our standard warranty is return-to-base. Onsite warranty is only available to users who are registered, for sites located in the defined areas/regions and for purchases that have been registered. | |
